By customer request, a traditionally shaped 7 string!
Solid ash body
Maple fret board
Agile AL075 bridge
Three Alnico V single coil pickups
Tailor your sound with 1 volume control, 2 tone controls, plus a 5-way pickup selector switch
Grover tuners with 18-1 turn ratio for ultra fine tuning
Black 2-ply pickguard gives this guitar a look of class
Measurements
Overall length: 40 1/4"
Scale length: 25"
Width of the lower bout: 12 3/4"
Width of the upper bout: 11"
Width of the neck at the nut: 1 7/8"
Width of the neck at the 12th fret: 2 3/8"
Width of the neck at the 22nd fret: 2 9/16"
Thickness of the neck at the nut: 7/8"
Pickups: 3 1/16" x 5/8"
String spacing at the nut: 1/4" (1 5/8" overall)
String spacing at the bridge: 3/8" (2 1/2" overall)
Humbucker route: 1 13/16" x 3 3/4" (Body is routed HSS)
Weight: only 8 pounds
|
