New SX Constellation Series!
Ultra light, one piece, solid, American swamp ash body (the body on this bass is worth the price alone!)
Dual cutaways allow access to the highest frets
One piece, bolt-on, Canadian maple neck with rosewood reinforcement and dual action truss rod
High mass (BB104) bridge for improved sustain
Improved (DJ430CR) tuners for precision tuning
D'addario strings
Two single coil pickups are controlled from two volume controls and one tone control for lots of sound variation
Pearloid pickguard
Maple fretboard with 20 jumbo, hand filed frets and pearloid block inlays
Polyurethane finish
Chrome hardware completes the look
Measurements:
Overall length 45"
Scale length: 34"
Width at the widest point: 13"
Body thickness: 1 1/2"
Width of the neck at the nut: 1 9/16"
Width of the neck at the 20th fret: 2 9/16"
Thickness of the neck at the first fret: 7/8"
Pickup dimensions at neck: 3 5/8" x 3/4"
Pickup dimensions at bridge: 3 11/16" x 3/4"
Weight: only 10 pounds
Wiring Diagram
Note: Since this is a one piece neck, adjusting the truss rod requires removal of the pick guard similar to the old style Fender one piece models.
|
