Special Heel and Body Contour For Extra Comfort !
Neck-thu design for improved sustain and playability
Graph Tec NV2 bridge with graphite string saver saddles
Body and neck contour for extra comfort and access to higher frets.
Two Type V Alnico humbucker pickups for warm, tradional sound
Solid mahogany arch top body
Bound body, neck, and headstock.
Improved Nickel plate hardware, including Nickel die-cast Grover tuners with 18-1 turning ratio for ultra fine tuning (Model 102-18N)
Improved wiring, improved pots (high voltage with brass shafts for reduced noise) and an improved pickup selector switch
Two volume and two tone controls, plus a three way pickup selector switch
5 piece neck-thru (maple/walnut)neck with 13.7" (350mm) radius neck for fast play and adjustable truss rod
Ebony fretboard with 22 Jumbo frets and real Mother-Of-Pearl Trapezodial inlays
The AL-3200 features D'addario strings installed at the factory and a professionally cut Graph Tec nut
Individually hand filed frets for professional feel and playability
Width of the neck at the nut: 1 5/8"; at the 21st fret: 2 3/16"
Neck taper/thickness at the 1st fret: 21.5 mm; at the 12th fret: 23.5mm
Overall length: 40"; Scale length: 24.7"
Body thickness: 2" at edge; Width at the widest point: 13"
Bridge pole spacing is 3", and the Tail piece pole spacing is 3 1/4"
Actual Weight is only 10 lbs
Wiring Diagram
|
