Special Heel Contour For Extra Comfort !
5 piece neck-through (maple/walnut)neck design for improved sustain and playability
13.7" (350mm) radius neck for fast play and adjustable truss rod
Body and neck contour for extra comfort and access to higher frets
Cepheus T-6 wide throw tune-O-matic bridge with graphite saddles
Two Type V alnico humbucker pickups for that warm, traditional sound
Solid mahogany, arch top body
Flame maple top
Bound body, neck, and headstock
The AL-3200 comes with improved wiring, improved pots (high voltage with brass shafts for reduced noise) and an improved pickup selector switch
Two volume and two tone controls, plus a three way pickup selector switch
Ebony fretboard with 22 Jumbo Frets and genuine mother of pearl trapezoid inlays The AL-3200 features D'addario strings installed at the factory and a professionally installed Graph Tech nut
Individually hand filed frets for professional feel and playability
Measurements
Overall length: 40"
Scale length: 24 3/4"
Width of the neck at the nut: 1 3/4" (44 mm)
Width of the neck at the 21st fret: 2 1/4" (57 mm)
String spacing at the nut: 5/16" (8 1/2 mm)
String spacing at the bridge: 3/8" (10 mm)
Neck taper/thickness at the 1st fret: 7/8" (21.5 mm)
Neck taper /thickness at the 12th fret: 15/16" (23.5 mm)
Width at the upper bout: 9 1/4"
Width at the lower bout: 13 5/16"
Body thickness at edge: 1 15/16"
Weight: only 10 pounds
How to pick the right AL model: AL Specification Comparison
Set Up Tips
Wiring Diagram
|
Your final shipping costs will depend on your location and the items you order. To determine your total shipping cost, please click on the “add to shopping cart” button, and enter your address information. You will have the opportunity to cancel your order after you are quoted a shipping price.
$499.99
|
|
