Special Heel and Body Contour For Extra Comfort !
Neck-thu design for improved sustain and playability
Body and neck contour for extra comfort and access to higher frets.
Graph Tech NVS2 bridge with string saver saddles!
Slim Neck Taper (thickness) at the first fret is 17mm and 21mm at the 12th fret. (vs: 21.5 mm at the 1st fret and 23.5mm at the 12th fret for the standard AL-3000 model)
Two Type V Alnico humbucker pickups for warm, traditional sound
Solid mahogany arch top body
Improved Nickel plate hardware, including Nickel die-cast Grover tuners with 18-1 turning ratio for ultra fine tuning (Model 102-18N)
High voltage pots with brass shafts for reduced noise
Improved sealed pickup selector switch
Two volume and two tone controls, plus a three way pickup selector switch
5 piece neck-thru (maple/walnut)neck with 13.7" (350mm) radius neck for fast play and adjustable truss rod
Ebony fretboard with 22 Jumbo frets and trap mother of pearl inlays.
The AL-3200 features D'addario strings installed at the factory and a professionally cut Graph Tec nut
Individually hand filed frets for professional feel and playability
Width of the neck at the nut: 1 5/8"; at the 21st fret: 2 3/16"
Overall length: 40"; Scale length: 24.7"
Body thickness: 2" at edge; Width at the widest point: 13"
Bridge pole spacing is 3", and the Tail piece pole spacing is 3 1/4"
Actual Weight is only 10 lbs
Wiring Diagram
|
Your final shipping costs will depend on your location and the items you order. To determine your total shipping cost, please click on the add to shopping cart button, and enter your address information. You will have the opportunity to cancel your order after you are quoted a shipping price.
$399.99
|
|
