Special Heel and Body Contour For Extra Comfort !
Neck-thu design for improved sustain and playability
Graph Tech NVS2 bridge with string saver saddles!
Body and neck contour for extra comfort and access to higher frets.
Graph Tech NVS2 bridge with String Saver saddles.
Two Type V Alnico humbucker pickups for warm, tradional sound
Extra wide neck for comfortable playing - Width of the neck at the nut: 1 3/4"; at the 21st fret: 2 1/4"
Solid mahogany arch top body
Bound body, neck, and headstock.
Improved Nickel plate hardware, including Nickel die-cast Grover tuners with 18-1 turning ratio for ultra fine tuning (Model 102-18N)
The AL-3100 comes with improved wiring, improved pots (high voltage with brass shafts for reduced noise) and an improved pickup selector switch
Two volume and two tone controls, plus a three way pickup selector switch
One piece Mahogany neck-thru with 13.7" (350mm) radius neck for fast play and adjustable truss rod
Ebony fretboard with 22 Jumbo frets and real Mother-Of-Pearl block inlays
The AL-3200 features D'addario strings installed at the factory and a professionally cut Graph Tec nut
Individually hand filed frets for professional feel and playability
Neck taper/thickness at the 1st fret: 21.5 mm; at the 12th fret: 23.5mm
Overall length: 40"; Scale length: 24.7"
Body thickness: 2" at edge; Width at the widest point: 13"
Bridge pole spacing is 3", and the Tail piece pole spacing is 3 1/4"
Actual Weight is only 10 lbs
Wiring Diagram
|
Your final shipping costs will depend on your location and the items you order. To determine your total shipping cost, please click on the add to shopping cart button, and enter your address information. You will have the opportunity to cancel your order after you are quoted a shipping price.
$625.00
|
|
